POLIFEMO-RADIO

User manual

Doc: POL_R_200_006_E

Version: 2.0

Page

8 of 11

Fig. 4

1. BNC for external antenna connection

2. 5 pole Nucletron connector for Radio output

5.6. DISABLING RADIO TRANSMISSION

To disable wireless event transmission, set the 4 dip switches of CHANNEL SELECTION

(Switches 4-7) to the position ON (see Figure 5). Switch the photocell off and switch it on again

with the On/Off switch to activate this mode.

Disabling transmission

Figure 5

1 2 3 4 5 6 7 8 9 10 11
